Key Specification:
• Radio Design: 2.4 GHz Single-Band Dual-Stream
• Transmission Protocol: IEEE 802.11b/g/n
• Operating Band: 802.11b/g/n: 2.400～2.483GHz
• Antenna: Directional antennas, 8 dBi
• Polarization: Horizontal: 70°, Vertical: 70°
• Bridging Distance: 500m (recommended)
• Spatial Streams: 2×2, MU-MIMO
• Memory/Flash: 64 MB/8 MB
• Maximum Throughput: Up to 300 Mbps at 2.4 GHz
• Max. Transmit Power: ≤100 mW(20 dBm) (adjustable)
• IP Rating: IP55
• Lightning Protection: ±6 KV(Common Mode)
• Installation: Wall-mounted/ Pole-mounted
• Dimensions （D x W x H): 165.5mm×68.7mm×42mm
• Weight: 0.3 kg
• Certification: CE

Highlight Features:
• RG-EST100-E can easily transmit data from 500m away in real time
• Factory-free configuration, without complex alignment
• IP55 Weatherproof, -30℃~60℃ guarantee stable operating at outdoor or elevator environment
• Support maximum 10 * 3MP cameras loading at 100m, 5 * 3MP cameras loading at 500m
• Visually Intuitive statistics monitoring on Ruijie cloud, easy maintenance at remotely
