Output

Max Configurable Power (Watts) : 6.0kWatts / 6.0kVA

Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage

Efficiency at Full Load : 94.0 %

Output Voltage Distortion : 1 %

Output Frequency (sync to mains) : 50/60 Hz +/- 3 Hz Sync to mains

Other Output Voltages : 220 V, 240 V

Load Crest Factor : 3 : 1

Topology : Double conversion online

Waveform type : Sine wave

Bypass : Internal bypass (automatic and manual)

Input

Input frequency : 40 – 70 Hz Auto sensing

Input voltage range for main operations : 110 – 300 60 % load, 176 – 300 Full loadV

Efficiency at Full Load : 94.0 %

Other Input Voltages : 220 V, 240 V

Batteries & Runtime

Battery type : Lead-acid battery

Typical recharge time : 5hour(s)

Nominal Battery Voltage : 240 V

Expected Battery Life (years) : 3 – 5

Battery Charge Power (Watts) : 1.17kWatts

Communications & Management

Interface Port(s) : DB-9 RS-232, Intelligent Smart Slot, USB

Control panel : Multifunction LCD status and control console

Emergency Power Off (EPO) : Yes

Available SmartSlot™ Interface Quantity : 1

Physical

Maximum Height : 220MM, 21.95CM

Maximum Width : 438MM, 43.8CM

Maximum Depth : 615MM, 61.5CM

Net Weight : 78.0KG

Shipping weight : 88.0KG

Shipping Height : 490MM, 49.0CM

Shipping Width : 870MM, 87.0CM

Shipping Depth : 600MM, 60.0CM

Color : Black

Conformance

Approvals : CE, EAC, TISI, UKCA

Standard warranty : 2 years repair or replace
